CHF 140.70
CHF 140.70
excl. VAT
Available: 2.0 Units
This combination does not exist.
Units of Measure: Units
Add to basket
Product information:
External lift/lower button and height adjustment potentiometer of the front linkage do not work
Selection of a standard valve is required to operate the front linkage.
1.make sure that all timer switches of the electro-hydraulic auxiliary control units (EHR) are in the OFF position.
2.turn the ignition key to the "ON" position, but do not start the engine. 3.press the timer switch.
3.press the timer switch of auxiliary control unit 1 and then, within five seconds, the timer switch of control unit no. 2.
4.the dot matrix display will show "FEhr", after two seconds this display will change to the currently preset control unit, for example "Ehr4".
5.Select the new preset control unit and press the timer switch of the control unit concerned three times. The display changes and shows the new setting, e.g. EHR1.
6.turn the ignition key to OFF; the new preset for the control unit for operating the front linkage is then stored.
